Huawei 98010894 s1730s-l4p4t-ma (8 10 / 100 / 1000BASE-T Ethernet ports, 4 port Poe +, AC power supply) monitoring private exchange




1 PD compatibility test button

POE: turn off the compatibility detection function of PD devices. Only PD devices conforming to 802.3af or 802.3at standards can be powered.

L e-poe: enable the compatibility detection function of PD devices. The device can detect PD devices that do not conform to 802.3af or 802.3at standards (or switch devices can detect standard PD as non-standard PD after external influence), and supply power to these PD devices.

24 Poe + 10/100/1000base-t Ethernet electrical interfaces: 34 10 / 100 / 1000BASE-T Ethernet electrical interfaces 4 grounding screws

Note: the minimum wire diameter required for grounding cable is 18awg.

5 AC power socket

Note: AC power cable is used in the supporting system.

Indicator light: the indicator lamp identification and meaning of s1730s-l4p4t-ma are the same as s1730s-l8p-a, please refer to the instructions of s1730s-l8p-a.

Power configuration: the power configuration mode of s1730s-l4p4t-ma equipment is built-in single AC power supply. Within s1730s-l4p4t-ma

124W can be used for POE power supply in the power supply. Under 802.3af and 802.3at protocol, full supply of 4-interface Poe is supported.

Heat dissipation principle: s1730s-l4p4t-ma equipment has no fan, and the heat dissipation type is natural heat dissipation.

Specification parameters

Overall dimension (width) × deep × (high)

L basic dimension (the depth is the distance of the structural member excluding the protrusion of the front and rear panels): 250mm × 180mm × 43.6mm

L maximum dimension (the depth is the maximum distance from the protruding port of the front panel to the protruding structural member of the rear panel): 250mm × 185.4mm × 43.6mm

Weight (including packing material) 2.47kg

Service port lightning protection specification common mode ± 7kV

Power port lightning protection specification difference model ± 6kV, common mode ± 6kV

Poe support

Rated voltage range AC input: 100V AC ~ 240V AC; 50/60Hz

Maximum voltage range AC input: 90V AC ~ 264v AC; 47Hz～63Hz

Maximum power consumption (100% flow) l without POE: 10W l Poe full load: 144W (poe:124w)

Typical power consumption (30% flow) 8W

Operating temperature range - 5 ° C～+45 ° C (0m-1800m altitude)

Note: 1800m-5000m, the maximum temperature specification decreases by 1 for every 220m elevation rise ° C。

The device does not support operating at ambient temperatures below 0 ° It starts at C.

Storage temperature range - 40 ° C～+70 ° C

Ambient noise (27 ° C. Sound power

No fan, no noise

The relative humidity range is 5% RH ~ 95% RH, non condensing

The working altitude is from 0m to 5000m

Part code 98010894
