Bosch Bosch nda-u-wmt suspended wall bracket, suspended wall bracket
Modular camera bracket and accessories
Suspended wall hanging support
Commercial product No.: nda-u-wmt | product No.: f.01u three hundred and twenty-four point nine three nine
The integrated rotation function ensures that the camera is always installed in a perfect horizontal position
Modular design for quick and easy installation
Weather resistant finish to maintain surface appearance
Anti damage design suitable for indoor and outdoor use
The modular camera rack and accessories are a series of racks, mounting adapters
Suspended media panels and monitoring cabinets, which can be used for a wide range of Bosch photography
Machine. These accessories are easy to install and can be used in combination to simplify multiple locations
While maintaining the same appearance and style.
function
Wall hanger
Wall racks support multiple installation scenarios, including direct installation using appropriate transfer racks
Mounted on walls, poles or corners. The integrated rotation function ensures a smooth installation
The machine is always in the horizontal position. This rack supports simple cable management and can also be connected
Connect other embedded erection boxes to match the connection of conduit.
It provides a safe and robust solution to straighten the camera in combination with the following accessories
Ground mounted on wall or ceiling:
? nda-u-psmb wall / ceiling hanger SMB
? nda-u-pa0 / 1 / 2 monitoring cabinet
? nda-u-wmp wall mounted support plate
? nda-u-cmt corner adapter hanger
? nda-u-pmal pole rack adapter hanger (large)
? nda-u-pmas pole rack adapter hanger (small)
Certification and approval
Environmental data
Salt spray iec60068-2-52
Vibration NEMA TS2
Environmental data
Impact iec60068-2-27
Impact ik10
Internal parts
Quantity element
1 wall hanging support
4 M5 x 16mm flat head Torx screwdriver (Galvanized)
1 thread sealing tape: PTFE tape
1 IP rubber plug
1 T25 plum blossom wrench
1 quick installation guide
Technical specifications
Mechanical specifications
Connecting plate size Φ 101.5 mm (4 inches)
Dimensions (W x H) 227.4 x 155.7 mm (9 x 6.1 in)
Weight 650 g (1.43 lb)
Ordering information
Nda-u-wmt suspended wall bracket
Universal wall mounting bracket for spherical camera, white
Order No. nda-u-wmt
parts
Nda-u-pmte suspension fitting extension, 50 cm
Extension pipe for universal pipe hanger, 50 cm (white)
Order No. nda-u-pmte
Nda-u-psmb suspended wall / ceiling support SMB
Ceiling mounted erection box (SMB) for wall mounting bracket or pipe hanger.
Order No. nda-u-psmb
Hanger interface adapter for nda-4020-pip autome 4000
Suspension panel for autodome IP 4000i.
Order No. nda-4020-pip
Nda-5030-pip nde-4 / 5000 hanger interface joint plate
Suspension medium panel for outdoor flexidome 4000i / 5000i.
Order No. nda-5030-pip
Nda-7010-pip flexidome 7000 hanger interface adapter
Suspension media panel for flexidome IP panoramic 7000.
Order No. nda-7010-pip
Nda-u-cmt corner adapter hanger
Universal corner hanger, white
Order No. nda-u-cmt
Nda-u-pa0 monitoring cabinet 24VAC
Monitoring cabinet, 24 VAC input, 24 VAC output, IP66
Order No. nda-u-pa0
Nda-u-pa1 monitoring cabinet 120VAC
Monitoring cabinet, 120 VAC input, 24 VAC output, IP66
Order No. nda-u-pa1
Nda-u-pa2 monitoring cabinet 230VAC
Monitoring cabinet, 230 VAC input, 24 VAC output, IP66
Order No. nda-u-pa2
Nda-u-pmal pole rack adapter hanger, large
Universal pole frame adapter bracket, white, large
Order No. nda-u-pmal
Nda-u-pmas pole rack adapter hanger, small
Rod rack transfer hanger (small)
Universal rod rack adapter hanger, white, small.
Order No. nda-u-pmas
Nda-u-wmp wall hanging support fixing plate
The back plate is used for universal wall hanging bracket, corner hanger and rod hanger, white
Color, IP66
Order No. nda-u-wmp
