Bosch Bosch vg5-613-ecs autodome 600 series 28x pal outdoor lifting camera
Vg5-613-ecs autodome 600 series 28x pal outdoor lifting camera
Analog 28x pal camera, outdoor hoisting protective cover (with transparent acrylic plexiglass spherical cover)
Business type: vg5-613-ecs
Product No.: f.01u two hundred and seventeen point six nine five
Autodome 600 series analog PTZ camera
Choice of 550 TVL 36x or 28x day/night cameras with 12x digital zoom and wide dynamic range
Progressive scan provides smooth and clear images when viewing details in a moving image
Sodium Vapor White Balance mode restores objects to their original color
AutoTrack II automated motion tracking
Advanced privacy masking
Advanced alarm control with rules engine
UTP transmission standard on all models
Cable compensation extends cabling distances
High-impact, heavy-duty, tamper resistant aluminum housing
High-speed 360-degree continuous pan
Preset tour and AutoPan modes
detailed information
Image sensor 1 / 4 inch type exview had CCD (progressive scan)
Effective pixel Pal: about 440000; 752 (horizontal) x 582 (vertical) NTSC: about 380000; 768 (horizontal) x 494 (vertical)
camera lens 36x zoom (3.4 – 122.4 mm) F1 6 to F4 five
Zoom movement speed NTSC, pal
Optical wide angle / optical tele – tracking focus on 4.0 seconds, 4.0 seconds
Optical wide angle / optical tele – tracking focus off 2.7 seconds, 2.7 seconds
Optical wide angle / digital tele 6.0 seconds, 6.2 seconds
Digital wide angle / digital tele 2.1 seconds, 2.3 seconds
focusing Automatic, can be controlled manually
aperture Automatic, can be controlled manually
field 1.7 ° to 57.8 °
Video output 1.0 Vp-p, 75 ohms
gain control Auto / manual / max (– 3 dB to 28 dB, 2 dB steps)
Aperture distortion correction Horizontal and vertical
Digital zoom 12x
Horizontal definition Typically 550 TV lines (NTSC, PAL)
synchronization Line locking (- 120 ° to 120 ° vertical phase adjustment) or internal crystal oscillator clock
Sensitivity (typical) 1 30 IRE , 50 IRE
Day mode
Sensitivity increase off 0.66 lux , 1.4 lux
Sensitivity increase on (NTSC: 1 / 4 second, 15x; PAL: 1 / 3 second, 16.7x) 0.04 lux , 0.1 lux
Night mode
Sensitivity increase off 0.104 lux , 0.209 lux
Sensitivity increase on (NTSC: 1 / 4 second, 15x; PAL: 1 / 3 second, 16.7x) 0.0052 lux , 0.0103 lux
shutter speed 1 / 1 to 1 / 10000 seconds, 22 steps
Signal to noise ratio (SNR) > 50 dB
white balance 2000 K to 10000 K
1. Unless otherwise specified, the test conditions are: F1 6； Shutter = NTSC 1 / 60s, pal 1 / 50s; Maximum AGC; No spherical cover. The transparent spherical cover needs to increase 0.09 aperture loss (90% light transmittance). The colored spherical cover needs to increase 0.47 aperture loss (60% light transmittance).
Image sensor 1 / 4 inch type exview had CCD (progressive scan)
Effective pixel NTSC：380,000 PAL：440,000
camera lens 28x zoom (3.5 – 98.0mm) F1 35 to F3 seven
Zoom movement speed NTSC , PAL
Optical wide angle / optical tele – tracking focus on 2.5 seconds, 2.5 seconds
Optical wide angle / optical tele – tracking focus off 1.7 seconds, 1.7 seconds
Optical wide angle / digital tele – tracking focus on 4.5 seconds, 4.9 seconds
Optical wide angle / digital tele – tracking focus off 1.7 seconds, 1.7 seconds
Digital wide angle / digital tele 2.0 seconds, 2.5 seconds
focusing Automatic, can be controlled manually
aperture Automatic, can be controlled manually
field 2.1 ° to 55.8 °
Video output 1.0 Vp-p, 75 ohms
gain control Auto / manual / max (– 3 dB to 28 dB, 2 dB steps)
Aperture distortion correction Horizontal and vertical
Digital zoom 12x
Horizontal definition 550 TV cable
synchronization Line locking (- 120 ° to 120 ° vertical phase adjustment) or internal crystal oscillator clock
Sensitivity (typical) 2 30 IRE , 50 IRE
Day mode
Sensitivity increase off 0.33 lux , 0.66 lux
Sensitivity increase on (NTSC: 1 / 4 second, 15x; PAL: 1 / 3 second, 16.7x) 0.02 lux , 0.04 lux
Night mode
Sensitivity increase off 0.066 lux , 0.166 lux
Sensitivity increase on (NTSC: 1 / 4 second, 15x; PAL: 1 / 3 second, 16.7x) 0.0026 lux , 0.0082 lux
shutter speed 1 / 1 to 1 / 10000 seconds, 22 steps
Signal to noise ratio (SNR) > 50 dB
white balance 2000 K to 10000 K
2. Unless otherwise specified, the test conditions are: F1 6； Shutter = NTSC 1 / 60s, pal 1 / 50s; Maximum AGC; No spherical cover. The transparent spherical cover needs to increase 0.09 aperture loss (90% light transmittance). The colored spherical cover needs to increase 0.47 aperture loss (60% light transmittance).
Embedded ceiling Indoor hoisting
Horizontal rotation range 360 ° continuous, 360 ° continuous, 360 ° continuous
Pitch angle 1 ° above horizontal, 18 ° above horizontal, 18 ° above horizontal
variable speed 0.1 ° / S - 120 ° / s, 0.1 ° / S - 120 ° / s, 0.1 ° / S - 120 ° / S
Preset bit speed Horizontal rotation: 360 ° / s, vertical pitch: 100 ° / s, horizontal rotation: 360 ° / s, vertical pitch: 100 ° / s, horizontal rotation: 360 ° / s, vertical pitch: 100 ° / S
Preset accuracy ± 0.1 ° (typical), ± 0.1 ° (typical), ± 0.1 ° (typical)
Embedded ceiling Indoor hoisting
input voltage 21-30 VAC 50/60 Hz , 21-30 VAC 50/60 Hz , 21-30 VAC 50/60 Hz
Power consumption, typical 15 W / 27 VA, 15 W / 27 VA, 51 w / 55 VA 3
3. (add 16 watts if vg4-shtr-xt kit is used)
Protect open video Peak current 10 Ka (ceramic gas discharge tube)
Protection on two-phase Peak current 10A, peak power 300W (8 / 20) μ s)
Protection on RS-232 / 485 Electrostatic protection ± 15 kV manikin
Protection on alarm input Peak current 17 A, peak power 300 W (8 / 20) μ s)
Protection on alarm output Peak current 2 A, peak power 300 W (8 / 20) μ s)
Relay output protection on Peak current 7.3 a, peak power 600 W (10 / 1000) μ s)
Power input protection (spherical camera) Peak current 7.3 a, peak power 600 W (10 / 1000) μ s)
Protection power output (hoisting arm power supply) Peak current 21.4 a, peak power 1500 W (10 / 1000) μ s)
VGA-FIBER-AN
explain Multimode fiber module
Compatible receiver LTC 4629 series
Optical fiber compatibility 50 / 125 micron, 62.5/125 micron, low loss multimode glass fiber, rated minimum system bandwidth of 20 MHz
Maximum distance 4.0 km (2.5 miles)
Light budget 14 dB
Connector One (1) st connector
Wavelength (video / data) 850 nm / 1310 nm
Sector / Title 16 independent sectors, each sector can be set with a 20 character title
shelter 24 individually configurable privacy masks
Preset bit 99, 20 character titles can be set for each position
Camera setup / control Dual phase, RS-232, RS-485, bilinx (coaxial cable)
communication protocol Biphasic, bilinx, PELCO P and PELCO D
Patrol route Two (2) types of tour routes: recorded tour routes - two (2) with a total duration of 15 minutes, preset tour routes - one (1) with up to 99 consecutive scenes and one (1) custom tour route with up to 99 scenes
Supported languages English, Czech, Dutch, French, German, Italian, polish, Portuguese, Russian and Spanish
Cable compensation
Maximum distance Precompensation is off and Precompensation is on
RG-59/U 1000 feet (300 meters), 2000 feet (600 meters)
RG-6/U 1500 feet (450 meters), 3000 feet (900 meters)
RG-11/U 2000 feet (600 meters), 4000 feet (1200 meters)
Cat 5 / UTP (passive receiver) 750 feet (225 meters), 1500 feet (450 meters)
Camera power supply 21-30 VAC, 50 / 60 Hz
Heater power supply 21-30 VAC, 50 / 60 Hz
control data Dual phase ± RS-232 Rx / TX or RS-485 ± - optional control data (dial switch can be selected)
video BNC/UTP
Audio line input 9 kohm (typ.), max. 5.5 Vp-p
Eolr alarm input (2) Programmable for "normally open", "normally closed", "normally open monitoring", "normally closed monitoring"
Alarm input (5) Programmable for "normally open" or "normally closed"
Relay output (1) Dry contact rated output: 2 A, 30 VAC
Open collector output (3) Max. 32 VDC, 150 mA
Embedded ceiling Indoor hoisting
Design rating IP54, 4 flame retardant, IP66, NEMA 4x, IP66, NEMA 4x
working temperature - 10 ° C to 40 ° C (14 ° f to 104 ° f), - 10 ° C to 40 ° C (14 ° f to 104 ° f), - 40 ° C to 50 ° C (- 40 ° f to 122 ° f) plus XT Kit: – 60 ° C to 50 ° C (– 76 ° f to 122 ° f)
Storage temperature - 40 ° C to 60 ° C (- 40 ° f to 140 ° f), - 40 ° C to 60 ° C (- 40 ° f to 140 ° f), - 40 ° C to 60 ° C (- 40 ° f to 140 ° f)
humidity 0% to 90% RH, no condensation, 0% to 90% RH, no condensation, 0% to 100% RH, condensation
4. With optional vga-ip54k-ic kit.
Polycarbonate transparent spherical cover VGA-BUBBLE-CCLR
Polycarbonate colored ball cover VGA-BUBBLE-CTIR
hoisting
Polycarbonate transparent spherical cover VGA-BUBBLE-PCLR
Polycarbonate colored ball cover VGA-BUBBLE-PTIR
Transparent high definition acrylic plexiglass VGA-BUBBLE-PCLA
Colored high definition acrylic plexiglass VGA-BUBBLE-PTIA
Lifting arm base
Hanging arm (without transformer) VG4-A-PA0
Hanging arm (120 / 230 VAC transformer) VG4-A-PA1 / VG4-A-PA2
Lifting arm with cable VGA-PEND-ARM
Mounting plate of vga-pend-arm VGA-PEND-WPLATE
Decorative frame for autodome series power supply VG4-A-TSKIRT
Optional mounting plate for boom mounting
Corner mounting plate VG4-A-9542
Autodome 600 series die
