Huawei 98010899 s1730s-l24p-ma, 24 10 / 100 / 1000BASE-T Ethernet ports, Poe +, AC power supply monitoring private switch
1 PD compatibility test button
POE: turn off the compatibility detection function of PD devices. Only PD devices conforming to 802.3af or 802.3at standards can be powered.
L e-poe: enable the compatibility detection function of PD devices. The device can detect PD devices that do not conform to 802.3af or 802.3at standards (or switch devices can detect standard PD as non-standard PD after external influence), and supply power to these PD devices.
2 24 Poe + 10 / 100 / 1000BASE-T Ethernet interfaces
3 grounding screw, indicating that the minimum wire diameter required for grounding cable is 18awg.
4. AC power socket, indicating that AC power cable is used.
98010899 s1730s-l24p-ma s1730s-l24p-ma (24 10 / 100 / 1000BASE-T Ethernet ports, Poe +, AC powered) 3550 CN: 98010899 s1730s-l24p-ma
Indicator light, the indicator light identification and meaning of s1730s-l24p-ma are the same as s1730s-l8p-a, please refer to the indicator light description of s1730s-l8p-a.
The power configuration of s1730s-l24p-ma device is built-in single AC power supply. The 370W built-in power supply of s1730s-l24p-ma can be used for POE power supply. Under 802.3af protocol, it can support 24 interface Poe full power supply at most, and 12 interface Poe full power supply under 802.3at protocol at most.
Heat dissipation principle: s1730s-l24p-ma equipment has two built-in fans, and the heat dissipation type is air cooling. The direction of air flow is left inlet and right outlet.
Specification parameters
Overall dimension (width) × deep × (high)
L basic dimension (the depth is the distance between the structural parts excluding the front and rear panels): 442.0 mm × 220.0mm × 43.6mm
L maximum dimension (the depth is the maximum distance from the protruding port of the front panel to the protruding structural member of the rear panel): 442.0 mm × 225.7mm × 43.6mm
Weight (including packing material) 4.07kg
Service port lightning protection specification common mode ± 7kV
Power port lightning protection specification difference model ± 6kV, common mode ± 6kV
Poe support
Rated voltage range AC input: 100V AC ~ 240V AC; 50/60Hz
Maximum voltage range AC input: 90V AC ~ 264v AC; 47Hz～63Hz
Maximum power consumption (100% flow)
L Poe without use: 34W l Poe full load: 418w (POE: 370W) typical power consumption (30% flow) 31W
