Bosch Bosch vg5-7230-epc4 autodome IP dynamic 7000 HD 30x zoom intelligent tracking network ball machine

Vg5-7230-epc4 autodome dynamic 7000 HD camera, 1080p30, 30x zoom, lifting type, transparent ball cover







Superb quality indoor/outdoor IP PTZ dome camera. 1080p HD resolution; 30x optical zoom; IVA; PoE; iSCSI/SD; multiple pre-programmed user modes; H.264 quad-streaming (CPP4); IP66; pendant mount, clear bubble.
Business type: vg5-7230- EPC4@94
Product No.: f.01u two hundred and ninety-one point two three seven
AUTODOME IP dynamic 7000 HD
High resolution, full HD PTZ camera with 1080p resolution and high-performance 30x zoom lens is suitable for shooting fine details in scenes with insufficient or uneven lighting

Intelligent tracking and alarm rule engines use onboard intelligent video analysis (IVA)

Enhance system flexibility with dual recording options (iSCSI and SD cards) and dual power options (high power Ethernet power supply (high power POE) / 24 VAC)

Fully configurable four bit stream, and video stream can be configured separately, based on Bosch general product platform (cpp4)

The installation is extremely easy and intuitive, with multiple pre configured user modes, allowing users to choose the camera configuration suitable for their application

detailed information
Image sensor Exmor CMOS sensor type 1 / 2.8

Effective pixels (pixels) 1944 x 1224 (2.38 MP)

camera lens 30x zoom 4.3mm to 129mm F1 6 to F4 seven

Field of view (FOV) 2.3 ° to 65 °

focusing Automatic, can be controlled manually

aperture Automatic, can be controlled manually

Digital zoom 12 times

gain control Auto / manual / Max

Aperture distortion correction Horizontal and vertical
Electronic shutter speed (AES) 1 / 1 second to 1 / 10000 second (22 steps)
dynamic range 90 dB (typ.)
Signal to noise ratio (SNR) > 50 dB
Backlight compensation (BLC) On / off
AUTODOME IP dynamic 7000 HD
characteristic
H264HD1080PoEHDRSD
Onvif
parts
Npd-6001a mid span, high power Poe, single port, AC input
Npd-6001a mid span, high power Poe, single port, AC input
High power, 60 W single port Poe mid span with AC input
Commercial type: npd-6001a
Product No.: f.01u two hundred and seventy-five point nine nine four
Vg4-a-psu1 PSU, 120VAC, applicable to autodome and mic7000
Vg4-a-psu1 PSU, 120VAC, applicable to autodome and mic7000
Power supply, 120VAC input, 24VAC output (at 96va).
Suitable for supplying power to autodome, MIC IP 7000 and Mic IP fusion 9000i cameras. White, aluminum shell with protective cover. Waterproof and dustproof, conforming to IP66 standard. Ik10 anti riot performance.
Business type: vg4-a-psu1
Product No.: f.01u 009.667; F.01U. 081.593; F.01U. two hundred and sixty-one point three seven seven
Vg4-a-psu2 power supply, 230VAC, autodome, mic7000
Vg4-a-psu2 power supply, 230VAC, autodome, mic7000
Power supply, 230VAC input, 24VAC output (at 96va).
Suitable for supplying power to autodome, MIC IP 7000 and Mic IP fusion 9000i cameras. White, aluminum shell with protective cover. Waterproof and dustproof, conforming to IP66 standard. Ik10 anti riot performance.
Business type: vg4-a-psu2
Product No.: f.01u 009.668; F.01U. 096.639; F.01U. 097.433; F.01U. 081.604; F.01U. two hundred and sixty-one point three seven eight
Vg4-a-pa0 lifting arm base
Vg4-a-pa0 lifting arm base
Lifting arm base, with power box for autodome series camera, no transformer, white
Commercial type: vg4-a- PA0@1
Product No.: f.01u ninety-seven point four three five
Vg4-a-pa1 lifting arm base with 120 VAC transformer
Vg4-a-pa1 lifting arm base with 120 VAC transformer
Lifting arm base with power box for autodome series cameras, equipped with 120 VAC transformer, white
Commercial type: vg4-a-pa1
Product No.: f.01u nine point six six three
